Components

Manganese rails

Branscheid wear strips reliably protect conveyor systems from abrasion and ensure precise guidance of the conveyor chain.

Manufactured from high-quality manganese hard steel, they offer outstanding wear resistance and an exceptionally long service life. Thanks to high-quality materials, a precise heat treatment process, and precise manufacturing, these wear rails function reliably over the long term even under extreme loads and significantly reduce maintenance requirements.

Request consultation

Drei robuste Schleissschienen aus Manganstahl zur Verschleißreduktion in industriellen Förderanlagen

Technische Zeichnung einer Schleissschiene mit Abmessungen und Winkeln der Führung

Production

Wear rails

Branscheid wear reils are made from high-manganese steel X120Mn12 (1.3401). The austenitic structure of this steel gives it its excellent toughness. While the hardness of the steel is between 200 - 220 HB when delivered, the surface hardness can increase to up to 600 HB due to strain hardening during operation. As a result, it only becomes harder in the stress area, but otherwise remains unbreakable and tough. This means that high-manganese steel is perfect for use as highly wear-resistant liner for conveyor chains.
